Engine and Transmission

Engine Capacity	177 cc
Engine Type	4- Stroke, 1- Cylinder, Air- Cooled Engine
Max Power	13 PS @ 7500 rpm
Max Torque	13.2 Nm @ 6000 rpm
Transmission	5 Speed Manual
Drive Type	Chain Drive
Clutch	Wet Multiplate
Bore	65.5 mm
Stroke	52.4 mm
Compression Ratio	9.1 : 1
Emisssion Standard	BS6 - 2
Fuel Type	12V 6Ah
Starting Mechanism	Self Start Only

Features

Instrument Console	Analogue and Digital
Speedometer	Analogue
Odometer	Digital
Tripmeter	Digital
Tachometer	Digital
Seat Type	Single

Features and Safety

Pass Light	Yes
Shift Light	Yes
Clock	Yes
Footrest	Yes
Display	Yes
Saree Guard	Yes
Kill Switch	Yes
Hazard Warning Indicator	Yes
High Beam Indicator	Yes
Side Stand Engine Cut-off	Yes

Mileage and Performance

Mileage (ARAI)	45 kmpl
Acceleration	0 - 60 kmph

Chassis and Suspension

Frame Type	Double Cradle Frame, Steel
Front Suspension	Ø30 mm telescopic fork / 110 mm
Back Suspension	Swingarm with 5-Way Spring Preload Adjustability, Travel - 64 mm

Dimensions and Capacity

Kerb Weight	135 kg
Fuel Tank Capacity	12 L
Reserve Fuel Capacity	2,4 L
Seat Height	790 mm
Ground Clearance	165 mm
Length	2005 mm
Width	805 mm
Height	1050 mm
Wheelbase	1320 mm

Electricals

Headlight Type	Halogen Bulb
Taillight	Halogen Bulb
Turn Signal	Halogen Bulb
Low Fuel Indicator	Yes

Tyres and Brakes

Front Tyre Size	80/100 - 17
Back Tyre Size	100/90 - 17
Tyre Type	Tubeless
Wheel Type	Spoke
Front Brake Type and Size	Disc, 270 mm
Back Brake Type and Size	Drum
Braking System	Single Channel

Performance

Top Speed

110 kmph

Motor & Battery

Max Power	13 PS @ 7500 rpm
Motor Type	12V, 6Ah
