Engine and Transmission

Engine Capacity	109.7 cc
Engine Type	4- Stroke, 1- Cylinder, Air- Cooled
Max Power	8.19 PS @ 7500 rpm
Max Torque	8.7 Nm @ 5500 rpm
Transmission	4 Speed Manual
Drive Type	Chain Drive
Clutch	Wet Multiplate
Bore	53.5 mm
Stroke	48.8 mm
Compression Ratio	10.0 : 1
Emission Standard	BS6 - 2
Fuel Petrol	Petrol
Starting Mechanism	Kick Start and Self Start

Features

Instrument Console	Analogue
Speedometer	Analogue
Odometer	Analogue
Tripmeter	Analogue
Seat Type	Single
Carry Hook	Yes

Features and Safety

Pass Light	Yes
Footrest	Yes
Saree Guard	Yes

Mileage and Performance

Mileage (ARAI)	65 kmpl
Acceleration	0 - 60 kmph, 6 s

Chassis and Suspension

Frame Type	Single Cradle Tubular
Front Suspension	Telescopic Fork
Back Suspension	5 Step Adjustable Hydraulic Shock Absorber

Dimensions and Capacity

Kerb Weight	113 kg
Fuel Tank Capacity	10 L
Reserve Fuel Capacity	1.5 L
Seat Height	780 mm
Ground Clearance	180 mm
Length	2025 mm
Width	705 mm
Height	1080 mm
Wheelbase	1265 mm

Electricals

Headlight Type	Halogen Bulb
Taillight	Halogen Bulb
DRLs (Daytime Running Lights)	Yes
Turn Signal	Halogen Bulb

Tyres and Brakes

Front Tyre Size	2.75 - 18
Back Tyre Size	3.00 - 18
Tyre Type	Tubeless
Wheel Type	Alloy
Front Brake Type and Size	Drum, 130 mm
Back Brake Type and Size	Drum, 110 mm
Braking System	SBT

Performance

Top Speed

90 kmph

Motor & Battery

Max Power	8.19 PS @ 7500 rpm
Battery Capacity	12V, 4Ah
