Engine and Transmission

Engine Capacity	109.7 cc
Engine Type	4- Stroke, 1- Cylinder, Air- Cooled
Max Power	8.19 PS @ 7350 rpm
Max Torque	8.7 Nm @ 5000 rpm
Transmission	4 Speed Manual
Drive Type	Chain Drive
Clutch	Wet Multiplate
Bore	53.5 mm
Stroke	48.8 mm
Compression Ratio	10.0. : 1
Emission Standard	BS6 - 2
Petrol Type	Petrol
Starting Mechanism	King Start and Self Start

Features

Instrument Console	Analogue
Speedometer	Analogue
Odometer	Analogue

Features and Safety

Pass Light	Yes
Footrest	Yes
Kill Switch	Yes
Saree Guard	Yes
Side Stand Engine Cut-off	Yes

Mileage and Performance

Mileage (ARAI)	90 kmph
Acceleration	0 - 60 kmph, 5 S

Chassis and Suspension

Frame Type	Single Cradle Tubular Frame
Front Suspension	Telescopic Oil - Damped Front Forks
Back Suspension	5 Step Adjustable Hydraulic Shocks

Dimensions and Capacity

Kerb Weight	112 kg
Fuel Tank Capacity	10 L
Reserve Fuel Capacity	2 L
Seat Height	790 mm
Ground Clearance	175 mm
Length	1950 mm
Width	705 mm
Height	1080 mm
Wheelbase	1236 mm

Electricals

Headlight Type	Halogen Bulb
Taillight	Halogen Bulb
DRLs (Daytime Running Lights)	Yes
Turn Signal	Halogen Bulb
Low Oil Indicator	Yes

Tyres and Brakes

Front Tyre Size	2.75 - 17 41P
Back Tyre Size	3.00 - 17 50P
Tyre Type	Tubed
Wheel Type	Alloy
Front Brake Type and Size	Drum, 130 mm
Back Brake Type and Size	Drum, 110 mm
Braking System	Synchronized Braking Technology (SBT)

Performance

Top Speed

90 kmph

Motor & Battery

Max Power	8.19 PS @ 7350 rpm
Battery Capacity	12V, 4Ah
